Lant Renold Hydro-service
Conectori:
Lanturile Renold Hydro-Service au rezistenta mare la coroziune si sunt o alternativă la lanturile din oţel inoxidabil.
Proprietati:
- crom hexavalent-free -puteti fi siguri ca este un lant de tip "prieten cu mediul";
- este de 30 de ori mai rezistent la coroziune decât lanturile tratate conventional la suprafata;
- nu se exfoliaza;
- capacitatea de încărcare este aceeasi ca la lanţul de oţel standard;
- nu se oxideaza in contact cu apa;
Lant Hidroservice BS cu un rand de zale
Referinta lant |
Detalii Tehnice |
Tip lant |
ISO Ref |
Pas(inch) |
Pas(mm) |
Latime int |
Diam rolei |
Latime za. |
Grosime za int. |
Grosime za ext. |
Diam. bolt |
Lung. bolt |
Forta de rupere |
Greutate (Kg/m) |
|
|
A |
A |
B |
C |
D |
E |
F |
G |
H1 |
|
|
GY06B1* |
06B-1 |
0.375 |
9.525 |
5.72 |
6.35 |
8.20 |
1.29 |
1.04 |
3.28 |
12.5 |
8900 |
0.39 |
GY08B1 |
08B-1 |
0.500 |
12.700 |
7.75 |
8.51 |
11.70 |
1.55 |
1.55 |
4.45 |
16.5 |
17800 |
0.70 |
111044 |
- |
0.500 |
12.700 |
3.30 |
7.75 |
9.60 |
1.13 |
0.98 |
4.09 |
9.8 |
8900 |
0.30 |
111046 |
- |
0.500 |
12.700 |
4.88 |
7.75 |
9.60 |
1.13 |
0.98 |
4.09 |
11.4 |
8900 |
0.35 |
110044 |
- |
0.500 |
12.700 |
5.21 |
8.51 |
11.70 |
1.55 |
1.55 |
4.45 |
14.5 |
17800 |
0.70 |
GY10B1 |
10B-1 |
0.625 |
15,875 |
9.65 |
10.16 |
14.60 |
1.55 |
1.55 |
5.08 |
18.8 |
22200 |
0,96 |
110054 |
- |
0.625 |
15.875 |
6.48 |
10.16 |
14.60 |
1.55 |
1.55 |
5.08 |
16.0 |
22200 |
0.81 |
GY12B1 |
GY12B-1 |
0.750 |
19.050 |
11.68 |
12.07 |
16.00 |
1.81 |
1.81 |
5.72 |
21.9 |
28900 |
1.22 |
GY16B1 |
16B-1 |
1.000 |
25.400 |
17.02 |
15.88 |
21.08 |
4.12 |
3.10 |
8.28 |
34.9 |
60000 |
2.80 |
GY20B1 |
20B-1 |
1.250 |
31.750 |
19.56 |
19.05 |
26.42 |
4.62 |
3.61 |
10.19 |
39.8 |
95000 |
3.85 |
GY24B1 |
24B-1 |
1.500 |
38.100 |
25.40 |
25.40 |
33.40 |
6.10 |
5.08 |
14.63 |
52.6 |
160000 |
7.45 |
Lant Hidroservice BS cu doua randuri de zale
Referinta lant |
Detalii Tehnice |
Tip lant |
ISO Ref |
Pas(inch) |
Pas(mm) |
Latime int |
Diam rolei |
Latime za. |
Grosime za int. |
Grosime za ext. |
Diam. bolt |
Lung. bolt |
Forta de rupere |
Greutate (Kg/m) |
|
|
A |
A |
B |
C |
D |
E |
F |
G |
H1 |
|
|
GY06B2* |
06B-2 |
0.375 |
9.525 |
5.72 |
6.35 |
8.20 |
1.29 |
1.04 |
3.28 |
23.0 |
16900 |
0.78 |
GH08B2 |
08B-2 |
0.500 |
12.700 |
7.75 |
8.51 |
11.70 |
1.55 |
1.55 |
4.45 |
30.4 |
31100 |
1.38 |
GY10B2 |
10B-2 |
0.625 |
15.875 |
9.65 |
10.16 |
14.60 |
1.55 |
1.55 |
5.08 |
35.4 |
44500 |
1.69 |
GY12B2 |
12B-2 |
0.750 |
19.050 |
11.68 |
12.07 |
16.00 |
1.81 |
1.81 |
5.72 |
41.4 |
57800 |
2.42 |
GY16B2 |
16B-2 |
1.000 |
25.400 |
17.02 |
15.88 |
21.08 |
4.12 |
3.10 |
8.28 |
66.8 |
106000 |
5.50 |
GY20B2 |
20B-2 |
1.250 |
31.750 |
19.56 |
19.05 |
26.42 |
4.62 |
3.61 |
10.19 |
76.7 |
170000 |
7.80 |
GY24B2 |
24B-2 |
1.500 |
38.100 |
25.40 |
25.40 |
33.40 |
6.10 |
5.08 |
14.63 |
101.3 |
280000 |
14.80 |
|
